Conveyor Belt PVC

Conveyor Belt, Sliding Belt – PVC Type

Stainless Steel 201 Frame (Non-adjustable Legs)

Polyvinylchloride (PVC)

• PVC offers high temperature resistance, tensile strength, and excellent resistance to cuts and punctures.
• PVC exhibits good wear resistance.
• PVC demonstrates good resistance to oils and is odor-resistant.
• PVC is robust and resistant to abrasion.

Product Examples:

Inverter Motor Motor Speed Ratio 30-40 meters/minute. Additional Charge: 7500 Baht

• Conveyor Belt PVC 500x1000x750 mm
• Speed 40 m/min, Adjustable Leg Height 100 mm.
• Load Capacity: 3 Kg. across the entire belt
• Price: 32,000 Baht

• Conveyor Belt PVC 500x1500x750 mm
• Speed 40 m/min, Adjustable Leg Height 100 mm.
• Load Capacity: 3 Kg. across the entire belt

• Conveyor Belt PU with Stainless Steel Frame: 400x1500x800 mm
• Speed 8-13 m/min, Adjustable Leg Height 100 mm.
• Load Capacity: 30 Kg. across the entire belt

• Conveyor Belt PVC with Aluminum Profile Frame: 300×1500 mm
• Speed 8-13 m/min, Adjustable Legs
• Load Capacity: 20 Kg. across the entire belt

• Conveyor Belt PU with Aluminum Profile Frame: 500×4500 mm
• Speed 8-13 m/min, Adjustable Legs
• Load Capacity: 30 Kg. across the entire belt

• Conveyor Belt PVC with Aluminum Profile Frame: 300×6000 mm
• Speed 8-13 m/min, Adjustable Legs
• Load Capacity: 30 Kg. across the entire belt

• Conveyor Belt PU with Stainless Steel 304 Frame + Stainless Steel 304 Table: 500×3000 mm
• Speed 3-5 m/min, Adjustable Legs
• Load Capacity: 30 Kg. across the entire belt

• Conveyor Belt PU with Stainless Steel 304 Frame + Stainless Steel 304 Table: 400×3000 mm
• Speed 3-5 m/min, Adjustable Legs
• Load Capacity: 30 Kg. across the entire belt

• Conveyor Belt PU with Stainless Steel 304 Frame: 500×1500 mm
• Speed 8-13 m/min, Adjustable Legs
• Load Capacity: 30 Kg. across the entire belt

• Steel Structure Stainless 304 Conveyor Solid

• Speed 3-5 m/min, Adjustable Legs
• Load Capacity: 40 Kg. across the entire belt

• Conveyor Belt PVC: 300x1500x750 mm
• Conveyor Belt PVC: 300x1000x750 mm
• Conveyor Belt PVC: 300x1200x300 mm
• Speed 8-13 m/min
• Weight Capacity: 2-3 Kg.

•
• Conveyor Belt PVC with Aluminum Profile Frame: 300×1500 mm
• Speed 8-13 m/min, Adjustable Legs
• Load Capacity: 30 Kg. across the entire belt

• Conveyor Mesh Stainless Steel 304 with Stainless Steel 304 Frame: 600×1000 mm
• Speed 3-5 m/min, Adjustable Legs
• Load Capacity: 40 Kg. across the entire belt

Conveyor Belt PVC Speed Specifications

**England**

**Thai Language**

Product on conveyor about 30kg

• Normal motor is 120W, Option: 200W, 400W, 600W

Differences Between PVC, PU, and Stainless Steel Conveyor Belts

1. Materials and Properties

   • PVC (Polyvinyl Chloride)
     ✅ Flexible and offers moderate chemical resistance.
     ✅ Lower cost compared to PU and stainless steel.
     ✅ Suitable for general applications such as packaging or material transport without oil and grease.
     ❌ Not resistant to high temperatures and may wear faster than PU.

   • PU (Polyurethane)
     ✅ Superior resistance to grease, oil, and chemicals compared to PVC.
     ✅ Smoother surface, ideal for food and pharmaceutical industries.
     ✅ Higher resistance to tearing and longer lifespan than PVC.
     ❌ Higher cost than PVC.

   • Stainless Steel
     ✅ High strength, resistant to impact and wear.
     ✅ Suitable for industries requiring high hygiene standards, such as food and beverage processing.
     ✅ Resistant to high temperatures and chemicals.
     ❌ High cost and potentially heavier.

2. Recommended Applications

   • PVC → General goods transport, e.g., packaging, electronics.
   • PU → Food and pharmaceutical industries, applications involving oil or grease contact.
   • Stainless Steel → Applications demanding high hygiene, or environments with high heat or humidity, e.g., food and beverage manufacturing, heavy industry.
